| 主要配置 Main Configuration | 100kWh Version版本 | |
| 基本信息 Basic information | 驾驶室颜色（领程蓝）Cab color (Blue) | 标配 Included/Standard |
| 驾驶室颜色（玉白色）Cab color (White) | 选配 Optional/Not Standard | |
| 驱动型式 Drive type | 4X2后驱 4×2 Rear-wheel drive | |
| 车辆类型 Vehicle type | 纯电动厢式运输车、仓栅式运输车、冷藏车 EV cargo box truck, warehousing & fencing truck，refrigerated truck | |
| GVW（T） | 6 | |
| 底盘尺寸（mm) Chassis dimensions | 5975×2020×2300 （不带导流罩 Without deflector ） 5975 x 2020 x 2995（带导流罩 With deflector） | |
| 整车尺寸 (mm) Vehicle dimensions | 厢式 Cargo box truck：5995×2175×3300 仓栅 Warehousing & fencing truck：5995×2200×3100 冷藏 Refrigerated transporter：5995×2260×3270 | |
| 轴距 (mm) Wheelbase | 3360 | |
| 整车前悬/后悬 (mm) Front/rear overhang | 1150/1485 | |
| 前后轮距 (mm) Front/rear track | 1615/1575 | |
| 整车接近/离去角(。) Approach/Departure Angle | 18/14 | |
| 货箱内部尺寸 (mm) Cargo Compartment Internal Dimensions | 厢式 Cargo box truck：4180x2100x2300 仓栅 Warehousing & fencing truck：4180×2100×400 冷藏 Refrigerated truck：4080×2100×2100 | |
| 货箱容积（m³）Cargo Compartment Volume | 厢式 Cargo box truck ：20；冷藏 Refrigerated truck：18 | |
| 货箱重量（kg) Cargo Compartment Weight | 厢式 Cargo box truck：680; 仓栅 Warehousing & fencing truck：750, 冷藏 Refrigerated truck：955 | |
| 额定载客人数 (人/座) Seating Capacity (Persons/seats) | 3 | |
| 底盘整备质量（kg) Chassis Curb Weight （Actual 实际） | 2430 | |
| 整备质量 (kg) Curb Weight （Actual 实际） | Cargo box 厢式 ：3110 Warehousing&fencing 仓栅：3180 Refrigerated 冷藏： 3385 | |
| 最高车速 (km/h) Max speed | 100 | |
| 驾驶室 Cab | 悬置 Suspension | 四点固定，前悬置机械扭力杆、后悬置机械橡胶减震 Four point fixation, front suspension mechanical torsion bar, rear suspension mechanical rubber shock absorber |
| 仪表 Instrument panel | 液晶仪表LCD instrument panel | |
| 车门锁 Door lock | 中控锁+电动门窗+遥控门锁 Central control lock+electric doors and windows+remote control door lock | |
| 换挡方式 Gear shift | 旋钮换挡 Rotary knob shift | |
| 主副驾顶部储物盒 Overhead storage box (Driver/Co-driver) | 标配 Included/Standard | |
| 主副驾顶遮阳板 Sun visor (Driver/Co-driver) | 标配 Included/Standard | |
| 座椅（主驾）Seat (Driver) | 织物座椅 Fabric seats | |
| 座椅（副驾）Seat (Co-drive) | 织物座椅 Fabric seats | |
| 翻转 Tilt | 可翻转 Rotatable | |
| 喇叭 Horn | 高低音喇叭 Compound horn | |
| 空调 Air conditioning | 电动空调 Electric air conditioning | |
| PTC | 标配 Included/Standard | |
| 多媒体(MP5+倒车影像+7吋触摸屏) Multimedia (MP5 + Rearview Camera + 7-inch Touchscreen ) | 标配 Included/Standard | |
| 后视镜 Rearview mirror | 普通后视镜（无电加热） Ordinary rearview mirror (without electric heating) | |
| 方向盘 Steering Wheel | 多功能方向盘+定速巡航 Multi functional steering wheel+cruise control | |
| 前大灯 Headlights | 卤素大灯 Halogen headlights | |
| 日间行车灯 Daytime running lights | 标配 Included/Standard | |
| 雾灯 Fog lights | 标配 Included/Standard | |
| 前下视镜 Front lower mirror | 标配 Included/Standard | |
| 导流装置 With deflector | 标配 Included/Standard | |
| 无导流罩 Without deflector | 选配 Optional/Not Standard | |
| 动力电池 Power Battery | 厂家 Manufacturer | 宁德时代 CATL |
| 容量(kWh) Capacity | 100.46 | |
| 冷却方式 Cooling method | 风冷 Air-cooled | |
| 电机 Motor | 厂家 Manufacturer | 德纳 Dana |
| 电机形式 Motor type | 永磁同步电机 Permanent magnet synchronous motor | |
| 冷却方式 Cooling method | 水冷water-cooling | |
| 额定/峰值功率(kW) Rated/peak power (kW) | 60/115 | |
| 额定/峰值扭矩(N.m) Rated/peak torque (N.m) | 135/350 | |
| 额定/峰值转速(r/min) Rated/Peak speed (r/min) | 4244/12000 | |
| 多合一 Multi in one controller | 包含功能 Included functions | MCU、气泵控制器 Air pump controller、DCDC、AC & PTC |
| 冷却方式 Cooling method | 水冷 Water-cooled | |
| 车架 frame | 尺寸 Dimensions（mm） | 180×60×5 |
| 悬架 Suspension | 型式 Type | 钢板弹簧 Leaf spring |
| 片数 No. of leaves | 前/后悬架标配 Front suspension ：3/3+3 前/后悬架选装 Rear suspension ：2/3+2 | |
| 轴桥 Axle | 前轴厂家/额定承载(T）Front axle manufacturer/rated load | 德纳 Dana 2.2T |
| 后桥厂家/额定承载(T）Rear axle manufacturer/rated load | 德纳 Dana 3.5T | |
| 主减速器速比 Final drive ratio | 15.58 | |
| 转向 Steering | 转向器型式 Steering type | 循环球式电动转向器 Circular ball electric power steering gear |
| 制动 Brake | 制动系统额定压力（Mpa）Brake system rated pressure | 1 |
| 制动器型式 Brake type | 厢式/仓栅 Cargo box/warehousing&fencing：前后鼓式 Front /rear drum； 冷藏 Refrigerated： 前盘后鼓 Front disc rear drum | |
| 制动型式 Brake system | 标配 Included/Standard：气刹Air brake | |
| 驻车制动型式 Parking brake type | 手动驻车 Manual parking | |
| 轮胎 Tire | 型号 Model | 7.00R16LT 8PR |
| 轮辋 Rim | 钢制轮辋 Steel wheel rims | |
| 电气设备 Eletrical Equipment | 蓄电池（Ah) Battery | 24V，两块电池 Two batteries，60Ah |
| 电源总开关 Main power switch | 标配 Included/Standard | |
| 车内电源（V）In-vehicl power supply | 24 | |
| USB充电口 USB charging port | 标配 Included/Standard | |
| 智能配置 Smart Features | TBOX | 标配 Included/Standard |
| 远程锁车 Remote lock | 标配 Included/Standard | |
| 低速蜂鸣 Low-speed alert | 标配 Included/Standard | |
| 其他附件 Other Accessories | 后下部防护 Rea underrun protection | 钢制 Steel |
| 侧防护 Side protection | 钢制 Steel | |
| 有液压尾板 Hydraulic tailgate | 选配 Optional/Not Standard | |
| 无液压尾板 Without hydraulic tailgate | 标配 Included/Standard | |
| 随车工具 Tools | 停车楔，三角警示牌、反光背心 Parking wedges, triangular warning signs, reflective vests | |
